| Suspension | 2：1/1：1 |
| Voltage | 380V |
| Ploe | 32 |
| Rating | S5（40%） |
| INS.Class | F |
| IP Code | IP41 |
| Brake | DC110V 2×2.2A |
| Max.Static Load | 6000kg |
| Weight | 720kg |
| Specification | Load (kg) | Lift Speed (m/s) | Sheave Diam (mm) | Rope Sheave (mm) | Current (A) | Torque (Nm) | Rated Speed (rpm) | Frequency (Hz) | Power (kW) |
| Suspension2:1 | |||||||||
| GTW10XL-121P0 | 1250 | 1.0 | φ550 | 6×φ10×16 | 19.3 | 1125 | 69 | 18.4 | 8.1 |
| GTW10XL-121P5 | 1.5 | 28 | 1125 | 104 | 27.7 | 12.3 | |||
| GTW10XL-121P6 | 1.6 | 33.5 | 1125 | 112 | 29.9 | 13.2 | |||
| GTW10XL-121P7 | 1.75 | 33.5 | 1125 | 122 | 32.5 | 14.4 | |||
| GTW10XL-122P0 | 2.0 | 35.9 | 1125 | 139 | 37.1 | 16.4 | |||
| GTW10XL-122P5 | 2.5 | 46 | 1125 | 174 | 46.4 | 20.5 | |||
| GTW10XL-123P0 | 3.0 | 54.6 | 1125 | 208 | 55.5 | 24.5 | |||
| GTW10XL-131P0 | 1350 | 1.0 | φ550 | 7×φ10×16 | 20.8 | 1215 | 69 | 18.4 | 8.8 |
| GTW10XL-131P5 | 1.5 | 29.7 | 1215 | 104 | 27.7 | 13.2 | |||
| GTW10XL-131P6 | 1.6 | 34 | 1215 | 112 | 29.9 | 14.2 | |||
| GTW10XL-131P7 | 1.75 | 34 | 1215 | 122 | 32.5 | 15.5 | |||
| GTW10XL-132P0 | 2.0 | 39.8 | 1215 | 139 | 37.1 | 17.7 | |||
| GTW10XL-132P5 | 2.5 | 48.3 | 1215 | 174 | 46.4 | 22.1 | |||
| GTW10XL-133P0 | 3.0 | 58.6 | 1215 | 208 | 55.5 | 26.5 | |||
| GTW10XL-161P0 | 1600 | 1.0 | φ550 | 8×φ10×16 | 23.8 | 1440 | 69 | 18.4 | 10.4 |
| GTW10XL-161P5 | 1.5 | 35 | 1440 | 104 | 27.7 | 15.7 | |||
| GTW10XL-161P6 | 1.6 | 39.9 | 1440 | 112 | 29.9 | 16.9 | |||
| GTW10XL-161P7 | 1.75 | 39.9 | 1440 | 122 | 32.5 | 18.4 | |||
| GTW10XL-162P0 | 2.0 | 46 | 1440 | 139 | 37.1 | 21 | |||
| GTW10XL-162P5 | 2.5 | 58.4 | 1440 | 174 | 46.4 | 26.2 | |||
| GTW10XL-163P0 | 3.0 | 68 | 1440 | 208 | 55.5 | 31.4 | |||
| GTW10XL-201P0 | 2000 | 1.0 | φ485 | 8×φ10×16 | 29.1 | 1520 | 79 | 21.1 | 12.6 |
| GTW10XL-201P5 | 1.5 | 43.4 | 1520 | 118 | 31.5 | 18.8 | |||
| GTW10XL-201P6 | 1.6 | 48.6 | 1520 | 126 | 33.6 | 20.1 | |||
| GTW10XL-201P7 | 1.75 | 48.6 | 1520 | 138 | 36.8 | 22 | |||
| GTW10XL-202PO | 2.0 | 55.5 | 1520 | 158 | 42.1 | 25.1 | |||
| GTW10XL-202P5 | 2.5 | 69.2 | 1520 | 197 | 52.5 | 31.4 | |||
| GTW10XL-251P0 | 2500 | 1.0 | φ485 | 9xφ10×15 | 34.8 | 1820 | 79 | 21.1 | 15.1 |
| GTW10XL-251P5 | 1.5 | 52 | 1820 | 118 | 31.5 | 22.5 | |||
| GTW10XL-251P6 | 1.6 | 58.2 | 1820 | 126 | 33.6 | 24 | |||
| GTW10XL-251P7 | 1.75 | 58.2 | 1820 | 138 | 36.8 | 26.3 | |||
| GTW10XL-252PO | 2.0 | 66.5 | 1820 | 158 | 42.1 | 30.1 | |||
| GTW10XL-251POA | 2500 | 1.0 | φ520 | 7×φ13×20 | 33.4 | 1910 | 73 | 19.5 | 14.6 |
| Suspension1:1 | |||||||||
| GTW10XL-101PO-1 | 1000/1050 | 1.0 | φ520 | 6×φ13×20 | 15.2 | 1475 | 37 | 9.9 | 5.7 |
| GTW10XL-101P5-1 | 1.5 | 21.3 | 1550 | 55 | 14.7 | 8.9 | |||
| GTW10XL-101P6-1 | 1.6 | 24.6 | 1550 | 59 | 15.7 | 9.6 | |||
| GTW10XL-101P7-1 | 1.75 | 24.6 | 1550 | 64 | 17.1 | 10.4 | |||
| GTW10XL-102PO-1 | 2.0 | 27.4 | 1550 | 73 | 19.5 | 11.8 | |||
| GTW10XL-102P5-7 | 2.5 | 34.3 | 1550 | 92 | 24.5 | 14.9 | |||
| GTW10XL-111P5-1 | 1150 | 1.5 | φ520 | 6×φ13×20 | 24.8 | 1790 | 55 | 14.7 | 10.3 |
| GTW10XL-111P6-1 | 1.6 | 27.8 | 1790 | 59 | 15.7 | 11.1 | |||
| GTW10XL-111P7-1 | 1.75 | 27.8 | 1790 | 64 | 17.1 | 12 | |||
| GTW10XL-112PO-1 | 2.0 | 31.5 | 1790 | 73 | 19.5 | 13.7 | |||
| GTW10XL-112P5-1 | 2.5 | 40.6 | 1790 | 92 | 24.5 | 17.2 | |||
