Wholesale Elevator Safety Polyurethane PU Buffer
| Elevator Polyurethane Buffer | |||||
| Model No. | Max Stroke(MM) | Size(mm) | P+Q (KG) | Install Size | Rated Speed |
| LD-HC-L1 | 70 | 65*80 | 200-1200 | 95*65*4*12 | ≤1.0m/s |
| LD-HC-L2 | 70 | 80*80 | 200-1200 | 108*80*4*12 | ≤1.0m/s |
| LD-HC-L3 | 88 | 80*100 | 200-2000 | 108*80*4*12 | ≤1.0m/s |
| LD-HC-L4 | 121 | 80*128 | 200-2000 | 108*80*4*12 | ≤1.0m/s |
| LD-HC-L5 | 72 | 100*80 | 500-2000 | 108*80*4*12 | ≤1.0m/s |
| LD-HC-L6 | 88 | 100*100 | 500-2200 | 128*96*4*14 | ≤1.0m/s |
| LD-HC-L7 | 114 | 100*120 | 500-2500 | 128*96*4*14 | ≤1.0m/s |
| LD-HC-L8 | 144 | 100*160 | 500-3000 | 128*96*4*14 | ≤1.0m/s |
| LD-HC-L9 | 177 | 100*200 | 500-2600 | 128*96*4*14 | ≤1.0m/s |
| LD-HC-L10 | 90 | 120*100 | 500-3000 | 160*126*4*14 | ≤1.0m/s |
| LD-HC-L11 | 165 | 120*192 | 1000-3500 | 160*126*4*14 | ≤1.0m/s |
| LD-HC-L12 | 121 | 130*150 | 800-4800 | 160*126*4*14 | ≤1.0m/s |
| LD-HC-L13 | 170 | 130*200 | 1000-4200 | 160*126*4*14 | ≤1.0m/s |
| LD-HC-L14 | 108 | 140*120 | 500-3000 | 160*126*4*14 | ≤1.0m/s |
| LD-HC-L15 | 165 | 150*180 | 1800-4000 | 160*156*4*14 | ≤1.0m/s |
| LD-HC-L16 | 199 | 150*240 | 1000-4500 | 160*156*4*14 | ≤1.0m/s |
| LD-HC-L17 | 184 | 160*200 | 1800-5800 | 160*156*4*14 | ≤1.0m/s |
| LD-HC-L18 | 144 | 200*160 | 1800-6000 | 246*196*4*16 | ≤1.0m/s |
| LD-HC-L19 | 173 | 200*200 | 1800-7500 | 246*196*4*16 | ≤1.0m/s |
| LD-HC-L20 | 198 | 200*220 | 1800-7800 | 246*196*4*16 | ≤1.0m/s |
| LD-HC-L21 | 225 | 200*250 | 1800-8000 | 246*196*4*16 | ≤1.0m/s |
| LD-HC-L22 | 180 | 200*250 | 2000-8000 | 320*250*4*18 | ≤1.0m/s |
| LD-HC-L23 | 220 | 250*250 | 2000-8200 | 320*250*4*18 | ≤1.0m/s |
| LD-HC-L24 | 299 | 250*320 | 2000-8500 | 320*250*6*18 | ≤1.0m/s |
| LD-HC-L25 | 230 | 320*250 | 2000-9000 | 400*315*6*22 | ≤1.0m/s |
