| Type | Elevator Parameter | Traction wheel specifications | ||||||
| Weight (kg) | Speed(m/s) | Height（m） | Torque(Nm) | Tractor wheel diameter (mm) | Wire Rope Diameter (mm) | Slot Number (pcs) | Groove Spacing | |
| IVM320-200E-3 | 320 | 0.40 | ≤25 | 105 | 200 | 8 | 3 | 12 |
| IVM400-200E-3 | 400 | 134 | ||||||
| IVM450-200E-3 | 450 | 152 | ||||||
| IVM320-210E-3 | 320 | 110 | 210 | |||||
| IVM400-210E-3 | 400 | 140 | ||||||
| IVM450-210E-3 | 450 | 160 | ||||||
| IVM320-200E-4 | 320 | 105 | 200 | 4 | ||||
| IVM400-200E-4 | 400 | 134 | ||||||
| IVM450-200E-4 | 450 | 152 | ||||||
| IVM320-210E-4 | 320 | 110 | 210 | |||||
| IVM400-210E-4 | 400 | 140 | ||||||
| IVM450-210E-4 | 450 | 160 | ||||||
| Type | Motor Parameter | Brake Parameter | |||||||
| Power (kW) | Rated Voltage (V） | Rated Current (A) | Rated Frequency (Hz) | Rated Speed (rpm) | Number Of Poles | Rated Voltage (V) | Rated Current (A) | Braking Torque(Nm) | |
| IVM320-200E-3 | 0.85 | 220/380 | 5.2 | 15.20 | 76 | 12 | DC110 | 2X1.2 | 2X180 |
| IVM400-200E-3 | 1.1 | 6.2 | |||||||
| IVM450-200E-3 | 1.2 | 7.2 | |||||||
| IVM320-210E-3 | 0.85 | 5.5 | 14.60 | 73 | |||||
| IVM400-210E-3 | 1.1 | 6.5 | |||||||
| IVM450-210E-3 | 1.2 | 7.5 | |||||||
| IVM320-200E-4 | 0.85 | 5.2 | 15.20 | 64 | |||||
| IVM400-200E-4 | 1.1 | 6.2 | |||||||
| IVM450-200E-4 | 1.2 | 7.2 | |||||||
| IVM320-210E-4 | 0.85 | 5.5 | 14.60 | 64 | |||||
| IVM400-210E-4 | 1.1 | 6.5 | |||||||
| IVM450-210E-4 | 1.2 | 7.5 | |||||||
