Tips of MVP ELEVATOR BOARD INV-SDC INV-SDCL
For LG elevators using the INV-SDC or INV-SDCL, if an electronic arrival indicator is being used on site with a voltage of 24VDC, the diode connecting D13 and D14 on the board needs to be disconnected. If a mechanical arrival indicator is used on site with a voltage of 48VDC, then the diode D13 and […]
Elevator Traction Steel Belt
What Is Elevator Traction Steel Belt? Traction steel belts refer to a new type of flexible traction component for elevators, where a composite material encases numerous fine steel wires. These belts usually have a flat shape, with surface patterns such as V-shaped grooves, wavy structures, or flat structures. The elevator composite elevator traction steel belt […]
Do You Want To Know About The Different Models And Functions Of The MAXIEZ Elevator Circuit Boards?
Machine Roomless MAXIEZ Elevator PCB Collection: Elevator Main Board : KCD-1161,KCD-1161A,KCD1151 Elevator Drive Board : ：KCR-1005B,KCR-1004B,KCR-1007B Elevator Door Control Board：DOR-1202A ,DOR-1201A,DOR-160C Elevator Drive Module Board：KCR-816B,KCR916B Elevator Car Operation Main Board：LHS-1032B Elevator Group Control Board: KCZ-1200A,KCZ-1203B Elevator COP Display Board：LHD-1040 , LHD-730AG11 Elevator Car Display Board：LHD-1040 Elevator HOP Display Board：LHH-1200,LHH-1232AG24,LHH-1232BG24, LHH-1232CG24,LHH-1232DG24 LHH-1005,EG21,DG21 Elevator HOP LOP Push Button Board: LHB-052A,G01…G05 […]
Elevator Inspection Box
Elevator inspection box is a tool used for elevator maintenance, which facilitates the maintenance personnel to maintain the elevator safely, reliably and conveniently. Usually, there are elevator car top inspection box and pit inspection box. What is the Function For Elevator Inspection Box? The primary function of the elevator inspection box is to provide a safe and efficient […]
Replacement and Differences of GEN2 Elevator AAA633Z Encoders
Substitutions between models of AAA633Z Elevator Encoders The AAA633Z1 is the most commonly used, typically found in GEN2 machine-room-less elevators with a capacity of less than 1000 kg. The cable of the AAA633Z1 encoder is a standard length of approximately 8 meters. The cable of the AAA633Z2 encoder is 2 meters long. The AAA633Z3 is […]
Escalator Step Demarcations
What is the demarcation on escalators? The escalator step demarcations is an edge finish for the steps, typically refer to the visual indicators, such as lines or patterns, that guide users on where to stand or walk. Escaltor/moving walk step edge strips are often made from materials such as PVC, rubber, or aluminum alloy, which […]
Escalator Safety Switches
What is an escalator safety switch? Escalator safety switch is a device designed to ensure the safe operation of escalators. In the event of abnormal conditions, such as a broken drive chain or motor failure, the safety switch detects the issue and immediately cuts off power, protecting passengers while using the escalator. How many types of […]
Differences between Escalator 506NCE and Escalator 510 508 Escalator Aluminum Steps
Elevator aluminum alloy steps are generally divided into two types: with frame and without frame. European-style steps are not distinguished by angle. Common aluminum alloy step models include 506SL, 506, 506NCE, 510 and 508 . The all-aluminum steps are 506, 510, and 506SL. The 506NCE typically uses framed steps, with five escalator demarcation lines. PS: 606 step is auto-walk pallet. […]
Introduction to Escalator Brushes
What Are Escalator Brushes For? Escalator brushes, also known as skirt deflector , are safety features installed on escalators. These brushes are securely mounted above the gap between the escalator steps and the side panel (skirt) of the escalator. The brushes serve a dual purpose: they help to prevent objects from getting caught in the […]
Tips of ECO3000 RTK 13KV-C 13KV-A Escalator Chain
AF-ESC-KO-0054 ECO3000 RTK 13KV-C 13KV-A Escalator Chain Procurement Guide 1. Escalator Chain Model RTK: Pitch 133.33mm, Roller Size 75*23.5*6204, Chain Plate Thickness 4.8mm, Long Pin Length 87mm, Long Pin Diameter 14.5mm, Outer Chain Plate 30mm, Inner Chain Plate 35mm. 2. Escalator Chain Model 13KV-C (13DH-C): Pitch 133.33mm, Roller Size 75*23.5*6204, Escalator Step Chain Plate Thickness 4mm, Upper Pin Diameter […]
Elevator Overspeed Governor & Tension Device
What is an elevator elevator overspeed governor tension device? Elevator overspeed governor tension device is a crucial part in the elevator’s safety protection system. It is used to control the elevator’s operating speed and ensure passenger safety. The main function of the tension device is to maintain the tension of the overspeed governor’s steel wire rope, ensuring that […]
Tips Of GEN2 Elevator Inverter PG Card
Extremely Expensive Inverter PG Card For GEN2 elevators, there’s a specific PG card used with the GEFRAN INVERTER, either AVY3150 or other models, that is priced several times higher than regular PG cards. PG cards are categorized into synchronous and asynchronous types, determined by the control method of the elevator’s traction machine. Please make sure […]
